Pharma Blister Feed Static Single Column Lifter/Tipper

Product Code: KR-2443005


Product Details
    The Lifter for Blister Feed for the pharmaceutical industry is designed to lift and turn a 140L container.
    It is a static execution with a chain driven operation and has a Dead Man control.
    The Lifter for Blister Feed is made entirely out of 304 grade stainless steel and complied with the high CE-Requirements and EU- and USDA regulations.
    As standard the Lifter for Blister Feed manually turns and opens the container. Automatic is available upon request.
    The maximum height if the lifter is 1950mm and other special vessels can be catered for with a max capacity of 150 kg.
    Technical Data
    Power supply: 400 V 50 Hz
    Control Voltage: 24 V DC
    Power consumption: 0,85 kW
    Ambient temperature: min. 4°C / max. 40° C
    Capacity: max. 150 kg.
    Tilting height: max. 2100 mm
    Tipping height: 1950 mm
    Total height: 2870 mm
    Lifting speed: 5 m/min
    Turning angel: 90°
    Weight: approx. 350 kg.
    Machine dimensions: 1562 x 733 x 2870 mm
    Pallet dimensions: 3100 x 1800 x 900 mm
    Please contact the office for more information or simply click enquire on the product to send a direct email to our sales team.
    Can’t find what you are looking for? We can build it Bespoke!
    We manufacture bespoke solutions so should you see something that is similar or have an idea in mind please contact the sales team who will be happy to help.

Additional Information

Weight 350 kg
Dimensions 1562 × 2870 cm
